SBC-IOT-LINK - NXP i.MX93 Single Board Computer
Extensive wireless and wired connectivity
OPTIMIZED FOR INUDSTRIAL CONTROL AND MONITORING
Ideal for cost-sensitive systems
The i.MX93 family of processors features advanced dual-core ARM Cortex-A55 processors which operate at speeds of up to 1.7 GHz. A general purpose ARM Cortex-M33, 250Mhz core processor enables low-power processing.
Top Features
CPU Core
| CPU | NXP i.MX9352, dual-core ARM Cortex-A55, 1.7GHz |
| RAM | 1GB – 2GB, LPDDR4 |
| Storage | 16GB – 64GB eMMC flash, soldered on-board |
| Real-Time Co-processor | ARM Cortex-M33, 250Mhz |
I/O
| RS485 CAN bus | Up-to 2x RS485 (2-wire) | CAN-FD ports Terminal-block connector |
| Digital I/O | 3x digital outputs / inputs 24V compliant with EN 61131-2, terminal-block connector |
| USB | 1x USB2.0 host port, type-C connector |
| Debug | 1x serial console via UART-to-USB bridge, micro-USB connector |
| NXP SDP programming port, micro-USB connector |
Network
| Cellular Modem | 4G/LTE CAT-1 bis cellular module, SIMCOM SIM7672 Worldwide LTE, UMTS/HSPA | |
| 4G/LTE CAT-4 cellular module, Telit LE910 Worldwide LTE, UMTS/HSPA | ||
| SIM card socket | ||
| WiFi and Bluetooth | 802.11ax WiFi 6 and Bluetooth 5.4 BLE Implemented with NXP IW611 module 1x RP-SMA antenna connector | |
| Wireless Mesh | Bluetooth mesh, Thread, Zigbee Nordic Semiconductor nRF52840 / Silicon Labs MGM240 | |
| LAN | 1x Gbit Ethernet, RJ45 connector |
